DC Breaker
|
630/ 1500/ 1250A |
BMS | ESMU- 10 II |
Switching power supply | Switching power supply |
Miniature circuit breaker | S202-C64/20/10 |
Size | 600/1760/600mm |
The bus cabinet is the DC side bus control unit of the energy storage battery system, which is connected with the high voltage box and storage. Intermediate unit capable of converter; The power pool system (stack) is installed in the bus cabinet. Switch off/circuit breaker (optional), three-level BMS (ESMU), and UPS power supply. Confluence ark. The electrical characteristics, heat dissipation performance, and safety performance of each component have been fully considered in the design. And operation and maintenance, reasonable space layout, compact structure, flexible configuration, and security. Full reliability and other characteristics. The stage BMS module (ESMU) in the bus cabinet, with CAN, Rs-485, RJ45 Ethernet communication interface, can be realized with a high voltage box, PCS/UPS or The communication function between EMS realizes the data communication and control of the energy storage battery
management system and protection.
No
|
Item
|
Para Range
|
Quantity
|
Function
|
1
|
DC Breaker
|
630/ 1500/ 1250A
|
1
|
Main loop protection
|
2
|
BMS
|
ESMU- 10 II
|
1
|
Display communication
contro
|
3
|
Switching power supply
|
35W/75W 24V
|
1
|
Power Supply
|
4
|
Miniature circuit breaker
|
S202-C64/20/ 10
|
/
|
Switch
|
5
|
Emergency stop switch
|
LA38-22ZS
|
1
|
scram protection
|
6
|
Repeaters
|
CR-MX024DC2L
|
/
|
Signal control and conversion
|
7
|
LED instruction
|
ED16-22DSR(G/Y/R)
|
/
|
status indicator
|
8
|
Surge protective devices
(spd)
|
Ex9UEP 20 3P
|
1
|
Lightning protection bus
|
9
|
Fuse
|
DC1500/ 1000V 300A
|
1
|
protection
|
10
|
Terminal strip
|
|
/
|
Communication power
signal conversion
|
Battery Type
|
Lithium Ion |
System Type | Stackable, Rack-mounted |
Model Number | SW76R82K-H9 |
Voltage | 76.8V*n |
Capacity | 120AH |
Communication | CANBUS/Modbus RTU/TCP/IP |
Product Certificate | IEC62619/CE/UN38 .3 |
Single Module Capacity |
5.12kwh
|
Nominal Voltage | 51.2V |
Installation Method | Stacked mode |
Dimension/module | 600*440*200mm |
Communication Protocol | CAN/RS485/RS232(WIFI Optional) |
Cell Type | LFP |
Energy Storage 30-86KWH Hybrid Lithium Battery Solar Power System 100kw with EMS
Model Number: | LFP3048 |
Capacity: | 48KWH |
Battery Rated Voltage: | 460V |
Dimensions(mm): | 1220*860*1850 |
Weight(kg): | 750 |
New Arrival 51.2V 2.5kWh 5kWh 10kWh 20kWh Sunway Stack Lithium Battery Energy Storage Battery
Model Number: | SW48B-HV-2500 |
Capacity: | 2.5-20KWH |
Battery Rated Voltage: | 48-384V |
Dimensions(mm): | 580*220*202.5 |
Weight(kg): | 23.5 |
