TSM-NEG2 1C.20

N-type i-TOPCon bifacial dual glass

Monocrystalline module


Performance Overview

High customer value

The star of LCOE (Levelized Cost Of Energy).Higher string power the feature effectively reduces BMS (Balance of System)and LCOE

More energy harvest with cutting-edge N-type i-TOPCon technology

Designed for compatibility with existing mainstream system components

High power up to 700W

Up to 22.5% module efficiency with high-density interconnect technology

SMBB (Super multi-busbar) technology for better light trapping effect, lower series resistance and improved current collection

High reliability

Minimized micro-cracks with innovative non-destructive cutting technology

Ensured PID resistance through cell process and module material control

Resistant to harsh environments such as salt, ammonia, sand, high temperature and high humidity areas

Mechanical performance up to 5400 Pa positive load and 2400 Pa negative load

High energy yield

Excellent product bifaciality and low irradiation performance, validated by 3rd party

Lower degradation:1% first year,0.4% annually thereafter

Lower temperature coefficient (-0.30%)

Up to 30% additional power gain from the back side depending on albedo
