sunway 51.2V 100Ah 200Ah 5Kwh 10Kwh lithium ion battery pack deep cycle lithium ion solar battery
| Model Number: | SWB48100 |
| Capacity： | 5-28KWH |
| Battery Rated Voltage: | 51.2V |
| Dimensions（mm）: | 442*460*180a |
| Weight（kg）: | 52 |
Advantages of lithium iron phosphate battery pack:
*Long life, lithium iron phosphate battery, cycle life of more than 5000 times.
*Rechargeable batteries usually work when fully charged and never discharge. No matter what state the battery is in, it can be charged and used without having to discharge and recharge.
*Small in size, light in weight and large in capacity, lithium-ion batteries with the same specifications and capacity are 2/3 the volume and 1/3 of the weight of lead-acid batteries.
|
Model
|
SWB48100
|
SWB48200
|
SWB48300
|
SWB48400
|
SWB48500
|
SWB48600
|
|
Battery Type
|
LiFePO4
|
|||||
|
Usable Capacity
|
4.8kWh
|
9.6kWh
|
14.4kWh
|
19.2kWh
|
24kWh
|
28.8kWh
|
|
Design Capacity
|
100Ah
|
200Ah
|
300Ah
|
400Ah
|
500Ah
|
600Ah
|
|
Nominal Voltage
|
48V(15 series)
|
|||||
|
Battery Internal Resistance
|
≤80mΩ
|
|||||
|
Cycle Life
|
≥5000cycles@80%DOD,25℃，0.5C
≥4000cycles@80%DOD,40℃，0.5C
|
|||||
|
Design Life
|
≥10 years
|
|||||
|
Charging Voltage
|
53.3V
|
|||||
|
Maximum Operating Current
|
100A
|
|||||
|
Discharge Cut-off Voltage
|
42.0V
|
|||||
|
Charging Temperature Range
|
0℃~45℃ (Under 0℃ extra heating mechanism)
|
|||||
|
Discharging Temperature Range
|
-20℃~55℃ (Under 0℃work with reduced capacity)
|
|||||
|
Storage Temperature
|
-10℃~35℃ @ 60%±25% relative humidity
|
|||||
|
Communication
|
RS232-PC,RS485(B)-PC,RS485(A)-Inverter,Canbus-Inverter
|
|||||
|
Certification
|
US38.3,MSDS,UL1973,IEC62619
|
|||||
|
Weight
|
52kg
|
85kg
|
156kg
|
208kg
|
260kg
|
312kg
|
|
Product Dimension
|
442*460*180mm
|
442*680*180mm
|
530*560*720mm
|
530*560*960mm
|
530*560*1200mm
|
530*560*1440mm
|
