Capacity | 51.2V100AH |
Chemistry | LFP |
Module Capacity (kWh) | 5 |
IP Level | IP54 |
Communication | CAN |
Cycle Times | 6000 |
Safety: LiFePO4 batteries are known for their excellent thermal and chemical stability. They are less prone to overheating and thermal runaway, making them a safer choice compared to some other lithium-ion chemistries.
Model
|
SW51B-HV-5000
|
|||||
Capacity
|
51.2V100AH
|
|||||
Layout
|
16S3P
|
16S4P
|
16S5P
|
16S6P
|
16S8P
|
16S10P
|
String
|
3
|
4
|
5
|
6
|
8
|
10
|
Rated Voltage
|
51.2V
|
|||||
Chemistry
|
LFP
|
|||||
Module Capacity (kWh)
|
5
|
|||||
Total Energy (KWH)
|
15
|
20
|
25
|
30
|
40
|
50
|
Useable Energy (KWH)
|
15
|
20
|
25
|
30
|
40
|
50
|
Cycle Times
|
6000
|
|||||
Battery Port
|
||||||
System Rated Voltage (V)
|
153.6
|
204.8
|
256
|
307.2
|
409.6
|
512
|
Recommend Charging Current (A)
|
50
|
|||||
Max Charging Current (A)
|
100
|
|||||
Max Discharging Current (A)
|
100
|
|||||
Communication
|
CAN
|
|||||
Basic Parameter
|
||||||
Discharge Temperature
|
-20℃~+50℃
|
|||||
Charge Temperature
|
0℃~55℃
|
|||||
Working Altitude (m)
|
<3000
|
|||||
Noise(dB)
|
<40
|
|||||
Cooling
|
Natural cooling
|
|||||
IP Level
|
IP54
|
|||||
Storage Temperature
|
0℃~35℃
|
|||||
DOD
|
0.9
|
|||||
Humidity
|
5%-58%
|
|||||
Size
|
||||||
Pack Size
|
570*400*160mm
|
|||||
System Size(mm)
|
570*400*740
|
570*400*900
|
570*400*1060
|
570*400*1220
|
570*400*1540
|
570*400*1860
|
DC Breaker
|
630/ 1500/ 1250A |
BMS | ESMU- 10 II |
Switching power supply | Switching power supply |
Miniature circuit breaker | S202-C64/20/10 |
Size | 600/1760/600mm |
Model Number | SW1000V200A |
Dimension (L*W*H)
|
570*400*160mm |
Rated Voltage | 1000V |
Module Capacity (kWh) | 5 |
Capacity | 200A |
Battery Type
|
Lithium Ion |
System Type | Stackable, Rack-mounted |
Model Number | SW76R82K-H9 |
Voltage | 76.8V*n |
Capacity | 120AH |
Communication | CANBUS/Modbus RTU/TCP/IP |
Product Certificate | IEC62619/CE/UN38 .3 |
New Arrival 51.2V 2.5kWh 5kWh 10kWh 20kWh Sunway Stack Lithium Battery Energy Storage Battery
Model Number: | SW48B-HV-2500 |
Capacity: | 2.5-20KWH |
Battery Rated Voltage: | 48-384V |
Dimensions(mm): | 580*220*202.5 |
Weight(kg): | 23.5 |
